inorganic room passenger elevator revolutionary elevator concept
se series of non machine room passenger elevators are well versed in the concept of environmental protection, saving energy and reducing consumption, saving construction area and improving design freedom, fully embodying green humanism. compared with the same weight class gear elevator, it can save 25% of electricity and save 10% of building area. se series of non machine room passenger elevators have broken through the premise that the elevator must set up the computer room, providing unlimited possibilities for the limited space of modern architecture.
is easy to integrate into the architecture and
se series of non machine room passenger elevators only need an independent track space without the computer room. architects and developers can design more freely.
saves building cost
se series of non machine room passenger elevators occupy less space, enabling you to make more effective use of building space. it can save construction time, material and cost. the design and efficient installation of the engine room and well way ensure that the installation of the elevator will not cause any impact on the project.
the pure utilization ratio of 100% building space
integrates the machine room with the well path, and puts the traction machine and the control cabinet all right in the well path, saving the space cost for the building and realizing the high profit and use rate of the building space 100%.
high integrated intelligent control system
full computer intelligent control system realizes the multi microcomputer, modularization and network control, and improves the data processing speed to a great extent. the high intelligent computer module set in the system is the most safe, accurate and efficient management control for the computer operation.
microcomputer group control management system
the group control system of
se series elevator is a high-speed network processing nerve center. it uses the "fuzzy calculation" method, based on the efficient and rapid genetic algorithm, calculates the best way of elevator operation in the building, and chooses the best and most timely ladder scheme for passengers.
target layer reservation wizard system
according to the optimized allocation of different target elevators, even at the peak period of work, the number of passengers is relatively reduced (compared with the previous generation system), allowing passengers to take a leisurely pace. several elevators have been allocated different target layers, reducing the number of stops and providing more efficient services for passengers.
intelligent staircase system
passengers only need to choose the target floor on the keyboard or touch screen before entering the elevator. the system will arrange suitable elevators for passengers to reach the designated floors.
a, the malpractice of stopping the traditional elevator by layer by layer
b, creating a more orderly environment
c, effective improvement of commuter hours congestion phenomenon
remote monitoring function
through the cable or wireless communication module, in the remote monitoring center of the elevator operation status and the elevator passenger situation in real time monitoring, so that the fault before the occurrence of the removal, to ensure the safety of passengers.
id/ ic card (identity)
id/ ic card is used to control the use of elevators. only with id/ ic card can the elevator be used, which greatly strengthens the safety of building management and makes users more comfortable.
new generation of permanent magnet synchronous gear free traction machine
germany se series elevator is the pioneer of permanent magnet synchronous gearless traction technology, and has opened up a new generation of energy-saving elevator. its core technology based on the concept of environmental protection successfully represents the future development direction of elevators. energy saving, saving space, reducing construction cost and elevator operation cost are the core characteristics of the core technology in the industry. and thoroughly solved the problem of environmental pollution caused by oil leakage from traditional tractors, and achieved the maintenance free and environmental protection requirements of motors..
se series energy regeneration and feedback device
can recycle up to 25% of the energy consumed by the elevator. especially when the lift is loaded or loaded, the energy generated by the motor will be converted into resistance heat energy and wasted. however, the se series of elevator energy regeneration and feedback devices will convert electrical energy into the normal electric current corresponding to the power grid, so that these newly generated currents can be used on other electrical equipment in the building to achieve substantial energy efficiency.
led energy saving lighting
uses the dc drive led lighting as the interior lighting. the power consumption is very low and the electric light power conversion is close to 100%. under the same lighting effect, it can save more than 80% of the energy saving compared with the traditional light source.
automatic lighting in sedan chair
uses the automatic lighting technology in the sedan chair, fully considering the humanization and energy saving and environmental protection requirements, to ensure that the light is in the state of extinguishing when no one is used, and does not consume electrical energy. when someone uses it, it opens automatically, runs low consumption and saves the power of.
.
precise position control system
the advanced sensor of carries out high precision real-time signal feedback on the motion state of the motor rotor, and realizes the precision of the car positioning in the well track to reach the millimeter level, and realizes the flat layer with almost no error. the reliable car displacement memory technology ensures the function of the elevator to stop the station, open the door ahead and maintain the safety level.
gate machine control system
the control system of the se series elevator adopts a double control system, one is controlled by the main controller of the control cabinet and the other is controlled by the main board in the sedan chair, which greatly reduces the failure of the elevator to open the door because of the failure of the control system of the door.
light screen protection
se series elevator, the use of sensitive and dense infrared light screen, the elevator door to form a light screen protection safety net, for any person or object into its detection plane can make a sensitive reaction, high safety performance, import and export.
